Heatshrink Tubing 2:1 Shielding

Shrinkflex Shielding 2:1

Shrinkflex 2:1 Shield heatshrink tubing is a unique dual wall combination of a polyolefin outer layer and an inner layer of conductive cloth with high frequency EMI shielding properties.

Shrinkflex Shield is flame retardant abrasion and chemical resistant, and is an ideal solution for for protecting wire and cable bundles while providing shielding from external interference.

Features

  • Mil-I-DTL-23053/5
  • Flame Retardant
  • Excellent High Frequency EMI Shielding
  • RoHS
  • Easily Installs Over Connectors & Splices

Product Sizes

Size

Part Number

Unshrunk Diameter

Shrunk Diameter

Bulk Box Put Up/4' Pcs.

Shop Box Put Up/4' Pcs.

Lbs / 100'

Price and Availability

3/16"

H2C0.19BK

4.8mm

2.4mm

12

2

0.28

PRICE AND AVAILIBILTY ON APPLICATION CONTACT US

1/4"

H2C0.25BK

6.4mm

3.2mm

12

2

0.47

3/8"

H2C0.38BK

9.5mm

4.8mm

12

2

0.61

1/2"

H2C0.50BK

12.7mm

6.4mm

12

2

0.72

3/4"

H2C0.75BK

19.1mm

9.5mm

12

2

1.18

1"

H2C1.00BK

25.4mm

12.7mm

12

2

1.7

1 1/2"

H2C1.50BK

38.1mm

19.1mm

12

2

2.55
